Description |
GreenFloors
tongue and groove CLIC floating floor for commercial and residential
applications. |
|
Size |
35 13/16” x 11 13/16” x 1/2" |
|
4 mm (5/32”) |
|
Middle layer: 6 mm (1/4”) (Exterior Grade Fiberboard) |
|
Bottom layer: 2 mm (5/64”) cork underlayment |
|
Density Fiberboard |
80 Kg/m3 (52.87 lb/ft3) water-proof |
|
Density Cork |
Wear Layer 34 lbs/ft3- Underlayment 13 lbs/ft3 |
|
Acousical Rating |
Concrete slab 8”: STC 58 IIC 68 NC 30 |
|
With drop ceiling: STC 60 IIC 73 NC 30 |
|
Compression Recovery |
ISO 9727 |
|
With loading of 38.5 lbs/in2 |
|
Initial: 10% Residual: 1.5% after 1 hour |
|
Finish |
5 coats UV-cured acrylic finish |
|
Shock Absorption |
UNE 56 817 74 Initial maximum indentation < 0.19 mm |
|
Maximum indentation after 1 hour < 0.08 mm |
|
Abrasion Resistance |
ASTM D 3884 |
|
Abrasion wheels H-18 with 1000 grams load |
|
400 wear cycles |
|
Formaldehyde |
Class E1, Danish Control Organization for wood based panels (HDF) To
classify E1, high-density fiberboard panels must contain less than 3
mg/100 g of product. |
|
Packaging |
6 planks per pack or 17.6 sq ft |
|
60 packs per pallet or 1056 sq ft |
|
Storage |
Planks must be stored horizontally |
|
Installation |
See installation instructions |
